How a Softener Works

What Is A Water Softener?

Determines when regeneration is necessary, the direction of water flow and the amount of time spent in each cycle

Holds the resin that exchanges sodium for hardness minerals and is under water line pressure

Determines when regeneration is necessary, the direction of water flow and the amount of time spent in each cycle

Holds the salt that makes the brine solution used to regenerate the softening resin.

A water softener removes hardness minerals (calcium and magnesium) through a process called ion exchange:

Raw water runs through a bed of sodium charged softening resin contained in a pressure tank.
Hardness ions attach to the resin, exchanging with the harmless sodium ions.
Eventually the resin contains only hardness minerals and has to be regenerated.
The control valve monitors water usage and determines when to regenerate.
The resin is backwashed to rinse away impurities.
A strong brine solution is then drawn through the bed and hardness ions are exchanged for sodium ions.
The hardness ions are then rinsed to the drain.
The softener is now ready to soften again
